Plywood for Structure Flooring Application
Standard: AS/NZS 2269 GB9846(Structural Plywood)
Surface Grade: CD-face sanded/black grade
Stress Grade: F8, F11, F14, F17, F22 Certified
Bond Type: A-Bond Phenolic Adhesive (WBP, 72h boiling)
Core Material: High-Density Eucalyptus / Birch/poplar
Description
Technical Parameters
Product Parameters
|
Brand |
ROGGE WOOD |
|
Standard |
AS/NZS 2269 GB9846(Structural Plywood) |
|
Surface Grade |
CD-face sanded/black grade |
|
Stress Grade |
F8, F11, F14, F17, F22 Certified |
|
Bond Type |
A-Bond Phenolic Adhesive (WBP, 72h boiling) |
|
Core Material |
High-Density Eucalyptus / Birch/poplar |
|
Surface Material |
Birch/Eucalyptus/poplar |
|
Sheet Size |
1200 x 2400mm |
|
Thickness Range |
7mm, 9mm, 12mm, 15mm, 17mm, 19mm, 21mm, 25mm |
|
Density |
650 kg/m³ - 700 kg/m³ |
|
Moistur conter |
6%~12% |
|
Emission Level |
Super E0 / E0 /E1(Compliance with Australian laws) |
Professional Factory Perspective
Our Rogge flooring series is processed with high-precision T&G milling machines to ensure a perfect interlocking fit, essential for squeak-free structural floors.
Technical Advantages & Details
Interlocking T&G Joint
The tongue and groove system with plastic inserts ensures a tight, stable connection between sheets, providing a continuous structural deck.
High-Density Structural Core
Balanced hardwood/pine multi-layered core with A-bond glue lines provides the high rigidity needed for floor spans without deflection.
Certified F17 Rating Stamp
Every sheet is clearly stamped with the Grade F rating and AS/NZS standard, ensuring engineering compliance on construction sites.
Edge Waterproof Sealing
Edges are treated with waterproof sealant to prevent moisture absorption and edge swelling during the construction phase.
Flooring Application Scenes
Residential House Sub-flooring
Installed over timber joists as a high-strength subfloor, providing a flat and durable surface for carpets, tiles, or hardwood finishes.
Industrial Mezzanine Decking
The F17 rating makes it suitable for heavy-duty mezzanine floors in warehouses and workshops, capable of supporting high point loads.
Timber Tone & T&G Palette
Flooring sheets feature the natural look of industrial timber, complemented by colorful plastic tongues for easy identification.
Palette: Natural Pine, Core Eucalyptus, Blue-Tongue Profile, Edge-Red Sealant.
Frequently Asked Questions (FAQ)
Q1: Why is Tongue & Groove (T&G) important for flooring?
A: T&G allows the sheets to lock together, transferring loads across the joint and preventing independent movement of sheets, which reduces floor 'squeaks'.
Q2: What is the benefit of the F17 stress grade?
A: F17 is a high-strength rating that allows for longer spans between floor joists and higher load-bearing capacity compared to lower F-grades.
Q3: Can I use this flooring plywood in wet areas like bathrooms?
A: While the glue is waterproof, the surface must be appropriately waterproofed with a membrane before installing tiles or other finishes in wet areas.
Q4: How many joists should support a standard sheet?
A: For residential flooring, joists are typically spaced at 400mm or 450mm centers. Always consult local building codes and engineering span tables.
Q5: Does the plywood require acclimatization before installation?
A: Yes, we recommend leaving the sheets on-site for at least 48 hours to adjust to the local humidity levels to minimize movement after installation.
Q6: What is the maximum load capacity of a 17mm F17 sheet?
A: A 17mm F17 sheet can typically support over 5.0kPa uniformly distributed load on a 450mm span, but always verify with specific project load requirements.
